Introduction

Ensure a smooth and efficient deployment with this comprehensive pre-installation guide for TimeTec Parking. Installing a parking system involves more than just plugging in devices. To guarantee a successful and timely deployment of TimeTec Parking system, it’s essential to ensure the site is fully prepared beforehand. Below is a detailed site readiness checklist that site managers, contractors, and clients should follow before installation. Completing this checklist before system installation helps avoid delays, minimize troubleshooting, and ensures optimal performance.



Process

1. Civil Work Preparation
Before any equipment is installed, basic groundwork must be completed:
      a. Foundation Base (Island): Ensure concrete bases (typically 2x10ft minimum) are ready for barrier gate and parking equipment mounting.
      b. Loop Coil Trenching: Ground must be saw-cut and ready for inductive loop installation based on the layout diagram.
      c. Conduit/Trunking Laid: Electrical and communication conduits must be pre-laid from the barrier gate to parking equipment.
      d. Protective Bollards (if required): Bollards installed to protect equipment from vehicle impact.




2. Power Supply Setup
Consistent power is crucial for system reliability:
      a. Power Points for All Equipment: Each boom gate, terminal, and payment kiosk should have a dedicated power point (240V AC).
      b. Proper Grounding: Prevents electrical surges and ensures safety for sensitive electronic components
      c. UPS Backup: Optional but highly recommended to keep the system running during outages.
Grouped object



3. Network Infrastructure
Stable communication is the backbone of a cloud-based system like TimeTec Parking:
      a. LAN Points at Key Locations: Ensure LAN cable (Cat6 or better) is pulled to:
            - Entry/exit terminals
            - Payment kiosk
            - Control room/server
      b. Internet Access: Required for cloud synchronization, monitoring, and system updates.
      c. Static IP or DHCP Reservation: Allocate static IPs to all parking devices for reliable operation.



4. Traffic Flow and Lane Readiness for LPR System
For License Plate Recognition (LPR) systems, proper lane setup is essential:
      a. Single-Lane Entry/Exit Control: Ensure each LPR lane handles only one vehicle at a time to avoid misreads.
      b. Vehicle Stopping Point Marked: Mark a clear stop line in front of the LPR camera for consistent plate capture.
      c. Lane Width Optimized: Recommended lane width is 3.0–3.5 meters. Use bollards pole to narrow down lanes if they are too wide.
      d. No Obstructions: Make sure no signboards, trees, poles, or lights block the camera’s view.
      e. Proper Lighting: Provide adequate lighting if the site operates at night to ensure clear visibility for LPR cameras.
      f. Speed Control Measures: Install speed bumps or signage to ensure vehicles slow down near the camera zone.
